GENE-APL5

Home > AAEON > Embedded Boards >
Embedded Single Board Computers > 3.5” SubCompact Boards

3.5” SubCompact Board with Intel® Pentium® N4200/ Celeron® N3350 Processor SoC

Product Feature

Intel® Pentium® N4200/ Celeron® N3350 Processor SoC
DDR3L 1866 MHz SODIMM x 1, up to 8 GB
VGA/LVDS/LVDS2 (HDMI Co-layout with LVDS2 Optional)
2 CH Audio, SATA 6.0 Gb/s x 1
Supports 8-bit Digital I/O , USB 2.0 x 4 , USB 3.2 Gen 1 x 2 , COM x 4
Mini Card x 1 (Half-size), mSATA x 1 (Full size)
DC 12V Only or +9~19V (Optional), AT/ATX Mode
Supports TPM (Optional)
4/5/8-wire Resistive Touch Screen Controller (Optional)

Introducing the all-new GENE-APL5

Small, powerful, and energy efficient.

Featuring the latest generation of Intel® low-power, 14 nm quad-core processors, dual gigabit LAN, and USB 3.0 for an energy efficient, easy-to-deploy, fan-less PC experience.

GENE-APL5 are powered by a high-performance 14nm Intel® Atom® N4200 quad-core 2.50 GHz processor (burst), with full support for USB keyboard/mouse input, and direct output via HDMI. The GENE-APL5 is fully 4K media playback capable with on-board HDMI output, making it ideal for deployment in IoT, kiosk, digital signage, and cubicle applications.

GENE-APL5 are a powerful, easy-to-use, and easy-to-manage solution suitable for a wide range of challenging deployment scenarios where size, noise, and management present difficulties.

Notice: Undefined variable: rs5 in /opt/lampp/htdocs/productview.php on line 633

Notice: Trying to get property 'tab_ap' of non-object in /opt/lampp/htdocs/productview.php on line 633

Notice: Undefined variable: title_ap in /opt/lampp/htdocs/productview.php on line 638

Notice: Undefined variable: detail_ap in /opt/lampp/htdocs/productview.php on line 639

บริษัท พีที ออโตเมชั่น (ไทยแลนด์) จำกัด

เลขที่ 9 อาคารภคินท์ ชั้น 9 ห้องเลขที่ 901 ถนนรัชดาภิเษก แขวงดินแดง เขตดินแดง กรุงเทพฯ 10400
โทรและแฟกซ์ : +66(0)-2020-3000
อีเมล์ : product@pt-automations.com
Facebook : facebook.com/ptautomations

จันทร์ ถึง ศุกร์ เวลา 9.00 น. – 18.00 น.

SYSTEM
FORM FACTOR	3.5" SubCompact Board
CPU	Intel® Pentium® N4200/ Celeorn® N3350 Processor SoC
CPU FREQUENCY	Up to 2.5 GHz
CHIPSET	Intel® Pentium® N4200/ Celeron® N3350 Processor SoC
MEMORY TYPE	DDR3L 1866MHz, SODIMM x 1
MAX. MEMORY CAPACITY	Up to 8GB
BIOS	UEFI
WAKE ON LAN	Yes
WATCHDOG TIMER	255 Levels
POWER REQUIREMENT	+12V OR +9~19V (optional)
POWER SUPPLY TYPE	AT/ ATX
POWER CONSUMPTION (TYPICAL)	Intel® N4200, DDR3L 1600MHz 8GB, 1.57A@ +12V
DIMENSION (L X W)	5.75" x 4" (146mm x 101.7mm)
OPERATING TEMPERATURE	32°F ~ 140°F (0°C ~ 60°C)
STORAGE TEMPERATURE	-40°F ~ 176°F (-40°C ~ 81°C)
OPERATING HUMIDITY	0% ~ 90% relative humidity, non-condensing
MTBF (HOURS)	128,000
CERTIFICATION	CE/FCC
DISPLAY
VGA/LCD CONTROLLER	Intel® Atom™ N4200/ N3350 Processor SoC integrate
VIDEO OUTPUT	VGA/LVDS/ LVDS2 (co-layout with HDMI, optional)
BACKLIGHT INVERTER SUPPLY	Yes
I/O
ETHERNET	Intel® i210/I211, 10/100/1000Base-TX, RJ-45 x 2
AUDIO	High Definition Audio Interface
USB PORT	USB 3.2 Gen 1 x 2 USB 2.0 x 4
SERIAL PORT	RS-232 x 2 , RS-232/422/485 x 2
PARALLEL PORT	SPP/EPP/ECP x 1 (Option, Shared with DIO)
HDD INTERFACE	SATA 3.0 x 1 +5V SATA power connector x 1
FDD INTERFACE	—
SSD	mSATA
EXPANSION SLOT	mSATA x 1 (Full-size) MiniCard x 1 (Half-size)
DIO	8-bit
SIM	x 1 (uSIM) (Optional)
TPM	TPM2.0 x 1 (Optional)
TOUCH	x 1 (Optional)
