The 2-Port Audio/Video Splitter is cascadable up to 2 levels. So you can link up to 3 monitors and headphones to the source PC using the AC650A-2
The splitter features easy-to-use front-panel select switches and support the VESA DDC, DDC2, DDC2B standards (for video out Port 1).
Plus, the splitter is compatible with a broad range of video interfaces, including VGA, SVGA, XGA, UXGA, QXGA, and multisync.
Video signal enhancement enables you to place monitors up to 213.2 feet (65 m) away.
| Compliance | |
| cUL | 0 |
| FCC | |
| UL | 0 |
| General | |
| Approvals | CE |
| Distance | 213.2 ft. (65 m) maximum |
| Interface | VGA, SVGA, XGA, UXGA, QXGA, and multisync |
| Pixel Frequency | 400 MHz |
| Power | Adapter: 12 VDC, 600 mA, 7.2 W |
| Resolution | 2048 x 1536 at 60 Hz maximum |
| Item Specifications | |
| Connectors | Video input:(1) HD15 F; Video output: (4) HD15 F; Audio input: 3.5-mm stereo F; Audio output: (4) HD15 F; (4) 3.5-mm stereo F |
| Dimensions | 1.7"H x 13.5"W x 4.1"D (4.3 x 34.3 x 10.4 cm) |
This product works with:
NOTE(s):
Product works with:
| Name | Type | Version | Release Date | |
| 2-Port and 4-Port Audio/Video Splitters | Manual | 13 May 2021 |
