Windows® 98/Me/XP and Windows 2000 compatible.
Use an external USB connection to get the extra COM ports you need.
Why install an internal serial adapter to get extra COM ports when using an external USB connection makes more sense? Our USB Hubs convert your serial devices to USB-adaptable peripherals without sacrificing serial connection speeds.
The hubs feature high-speed UARTs with 128-byte FIFO transmit buffers and 384-byte FIFO receive buffers. With data rates of up to 921 kbps for RS-422/485 and 460 kbps for RS-232, these hubs are among the fastest USB serial devices in the industry!
They're also ideal for connecting devices in harsh environments where communication lines may be affected by noise and voltage spikes. Not only do the USB Hubs give you industrial-quality serial connections, but they also support automatic RS-485 data enable/disable and include a DB9 connector that's backward-compatible with PCI and ISA RS-422 products.
The USB Hubs connect easily to peripheral serial devices in external plug-and-play fashion. Because they're hot-swappable, you can install them without having to power down your PC.
Each hub comes with all necessary drivers, utilities, and help files for quick setup in Windows 98, Windows Me, Windows 2000, and Windows XP operating systems. Simply load the included software drivers, then connect the hub to your USB port and a serial device (printer, bar-code scanner, etc.). The hub even autoconfigures itself, enabling hassle-free, seamless integration into your existing application.
Choose from three models. You can configure each of the ports individually using internal DIP switches.
| General | |
| CE Approval | Yes |
| Communication Chip | High-speed, USB-to-serial interface (128-byte FIFO transmit, 384-byte FIFO receive) |
| Distance (Maximum) | RS-232: 50 ft. (15.2 m); RS-422/RS-485: 4000 ft. (1219.2 m) |
| Operating Environment | Temperature: 32 to 158° F (0 to 70° C); Humidity: 10 to 90% noncondensing |
| Power | From the USB bus (as long as the device is connected directly to a powered PC or hub) |
| Speed | RS-232: 460.8 kbps; RS-422/RS-485: 921 kbps |
| Item Specifications | |
| Connectors | Serial: (2), (4), or (8) DB9 M; USB: (1) Type B F |
Product Includes:
| Name | Type | Version | Release Date | |
| USB Hub Data Sheet | Datasheet | 30 June 2021 |
