Intel® Pentium® N4200 (4C): 1.1GHz, up to 2.5GHz, TDP 6W Intel® Celeron® N3350 (2C): 1.1GHz, up to 2.4GHz, TDP 6W *Wait for E3900 series in 2019 within ATRF according
SYSTEM MEMORY
DDR3L, memory down, up to 4GB
CHIPSET
Intel® SoC
ETHERNET
Realtek 8111G x 2 10/100/1000Mbps, RJ-45 x 2
BIOS
AMI BIOS
WAKE ON LAN
Yes
WATCHDOG TIMER
255 Levels
EXPANSION INTERFACE
M.2 2230 E key (For WIFI/BT Module)
POWER REQUIREMENT
Normal: +12V
POWER SUPPLY TYPE
Lockable
POWER CONSUMPTION
Intel®Pentium®N4200@ 1.1GHz,DDR3L 4GB 1.43A@+12V
SYSTEM SIZE
4.8" x 3.15" x 2" (122 mm x 72 mm x 50 mm)
GROSS WEIGHT
0.88 lb (0.4 kg)
OPERATING TEMPERATURE
32°F~ 122°F (0°C ~ 50°C)
STORAGE TEMPERATURE
-40°F ~ 176°F (-40°C ~ 80°C)
HUMIDITY
0% ~ 90% relative humidity, non-condensing
MTBF
191,000
DISPLAY
CHIPSET
Intel® SoC
VIDEO OUTPUT
HDMI 1.4
TOUCH
—
I/O
STORAGE/SSD
M.2 2280 (B Key) x 1 eMMC 32GB, up to 128GB (optional)
USB PORT
USB 3.2 Gen 1 x 2 (Rear IO) USB2.0 x 2 (Internal option)
SERIAL PORT
—
AUDIO
—
EXPANSION SLOT
RS-232 x 1, RS-232422/485 x 1 (Optional)
CERTIFICATION
CERTIFICATION
CE, FCC
