Input/Output Interface |
| Alarm Contact Channels | 1 relay output with current carrying capacity of 1 A @ 24 VDC |
Ethernet Interface |
10/100/1000BaseT(X) Ports
(RJ45 connector) | 1 |
| Standards | IEEE 802.1X for authentication
IEEE 802.3 for 10BaseT
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3af for PoE
IEEE 802.3u for 100BaseT(X) |
| Total Port Count | 1 |
| Highest Speed | 1G |
| Connections | PoE |
Ethernet Software Features |
| Management | IPv4, SNMPv1/v2c/v3, Syslog, TCP/IP, Telnet, TFTP, Web Console,
Wireless Search Utility |
| Security | HTTPS/SSL, RADIUS, SSH |
| Time Management | NTP Client, SNTP |
Serial Interface |
| Console Port | RS-232 (TxD, RxD, GND), 8-pin RJ45 (115200, n, 8, 1) |
| Flow Control | RTS/CTS, XON/XOFF |
| Parity | None, Even, Odd, Space, Mark |
Serial Signals |
| RS-232 | TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
Wireless Access Control |
| Controller Failover Mode | 1-on-1 hot backup |
| Handover Time | 50 ms |
| WLAN Products Supported | 110 radios |
Power Parameters |
| Input Current | 0.6 A @ 12 VDC, 0.15 A @ 48 VDC |
| Input Voltage | 12 to 48 VDC, Redundant dual inputs |
| Source of Input Power | PoE (IEEE 802.3af) |
Physical Characteristics |
| Housing | Metal |
| IP Rating | IP30 |
| Dimensions (without ears) | 52.85 x 135 x 105 mm (2.08 x 5.32 x 4.13 in) |
| Weight | 1,060 g (2.34 lb) |
| Installation | DIN-rail mounting, Wall mounting (with optional kit) |
Environmental Limits |
| Operating Temperature | Standard Models: -10 to 60°C (14 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
Storage Temperature (package
included) | -40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
Standards and Certifications |
| EMC | EN 55032/24 |
| EMI | CISPR 32, FCC Part 15B Class A |
| EMS | IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8 PFMF |
| Railway | EN 50121-4, EN 50155 |
| Safety | EN 60950-1, IEC 60950-1, UL 60950-1 |
Declaration |
| Green Product | RoHS, CRoHS, WEEE |
MTBF |
| Time | 447,425 hrs |
| Standards | Telcordia SR332 |
Warranty |
| Warranty Period | 5 years |
| Details | See www.moxa.com/warranty |
