RTC-1010M

Home  >   AAEON  >   Rugged Mobile Devices  >
Rugged Tablet Computers

10.1" Semi-rugged Tablet Features With Intel® N3350 / N4200 Processor With Windows®

Product Feature

  • 10.1" WXGA (1280 x 800) 300-nit TFT LCD (Default)
  • Intel® Celeron™ N3350 1.1GHz Dual Core Up to 2.4GHz (N4200 Optional)
  • Onboard DDR3L Memory, 4GB (Default)
  • eMMC 64GB (mSATA III Up to 512GB Optional)
  • Projected Capacitive Multi-Touch Screen
  • WiFi 802.11b/g/n, Bluetooth 4.2, LTE (Optional)
  • 2MP Front and 8MP Rear Camera
  • RS-232/422/485 COM Port + 10/100/1000 Base-T RJ45 (Optional)
  • USB 3.2 Gen 1 x 2 (USB Type-C x 1), USB 2.0 x 2
  • 2D Barcode Scanner & Smart Card Reader (Optional)
  • HF RFID Reader (Optional)
  • MSR Reader (Optional)
  • Up to 3 GNSS, GPS+Galileo(Default), GLONASS, BeiDou (Optional)
  • One Hot-swappable Battery + Internal Battery, Up to 44W Battery Capacity
  • IP54 Compliant, Drop 76cm
  • Programmable Function Key: F0, F1, F2, F3, Volume Up/Down, With LED Illumination
  • Windows® 10 IOT

The RTC-1010M 10.1” Sunlight Readable Semi-Rugged Tablet from AAEON is powered by Intel Celeron N3350 or Pentium N4200 (formerly Apollo Lake). It features a wide range of options and rich features. It is powerful, flexible, and IP54 certified, making it built for business.

The RTC-1010M handheld computer comes standard with a choice of Windows 10 IoT , making it easy integrate into existing workspaces. The RTC-1010M is powered by Intel Celeron N3350 or Pentium N4200, formerly Apollo Lake. It also features a range of I/O interfaces, including Micro HDMI, USB 2.0, USB 3.2 Gen 1, and USB Type-C. It also comes with slots for Micro SD and SIM cards and includes a hot-swappable battery pack, meaning the RTC-1010M doesn’t need to shut down or recharge to keep up with work.

The RTC-1010M also has many options customers can choose from. These include a 2D barcode scanner, smart card reader, magnetic stripe card reader (MSR), and a range of accessories to support working with the RTC-1010M. AAEON manufacturer support also means the RTC-1010M can be custom built for the specific and unique needs of your application.

Semi-Rugged design means the RTC-1010M handheld computer is built for the demands of a workplace. The RTC-1010M is IP54 certified waterproof and dustproof, as well as drop tested to a height of 76cm (~30 inches). Its screen is also sunlight readable (optional), allowing easy operation both indoors and outdoors. Customized firmware is available for the RTC-1010M that enables users to operate the touchscreen while wearing gloves.

What sets the RTC-1010M Semi-Rugged Tablet handheld computer apart is its combination of support and features. It comes with durability and flexibility not found in consumer tablets, and is an affordable solution to fully rugged tablets. Additionally, AAEON offers support that is unparalleled to ensure our products continue to function as long as your business is open.

SYSTEM
PROCESSORIntel® Celeron™ N3350 1.1GHz Dual core up to 2.4GHz Intel® Pentium™ N4200 1.1GHz Quad core up to 2.5GHz
OPERATING SYSTEMWindows® 10 IOT Enterprise SAC
MEMORYOnboard DDR3L 4GB (Default)
STORAGEeMMC 64GB (mSATA III up to 512GB via inside mini-card slot, Optional)
DISPLAY10.1" WXGA (1280x800) 300-nit TFT LCD
With Projected Capacitive Multi-Touch Screen
I/O PORTMicro-HDMI port x 1
SIM card slot x 1
Micro-SD card slot x 1
Audio jack x 1
USB 3.2 Gen 1 x 2 (USB Type-C x 1)
USB 2.0 x 2, DC-in jack x 1, RS-232/422/485 COM Port x 1 (Optional),
10/100/1000 Base-T RJ45 x 1 (Optional),
Smart card reader x 1 (Optional, Without IP protection),
MSR reader x 1 (Optional, Without IP protection)
COMMUNICATIONWi-Fi 802.11 b/g/n Bluetooth v4.2 (EDR + BLE)
NAVIGATIONUp to 3 GNSS, GPS + Galileo(Default), GLONASS, BeiDou (Optional)
WWAN (OPTIONAL)LTE via mini-card slot (Optional)
CAMERA2MP front camera
8MP rear camera with flash
SENSORG-sensor, E-compass, Gyro-sensor, Light-sensor
EXPANSION SLOTInside mini-card slot x 1, Mini-card slot x 1, Docking connector: USB 2.0 x 1
BARCODE SCANNER (OPTIONAL)2D Barcode scanner, OPTICON MDI-4100-USB (Optional)
HF RFID (OPTIONAL)ISO 15693 (R/W)
ISO 18092 (R/W)
ISO 14443-A (R/W)
ISO 14443-B (Only Read UID)
Depend on card type
PHYSICAL KEYF0 or Windows (Windows Start Key),
F1(BCR Trigger Button (When BCR is enabled)),
F2(Screenprint), F3(Ctrl+Alt+Del as Soft Reboot),
Volume Up, Volume Down
MECHANICAL
COLORBlack & Dark Gray
DIMENSIONS (W X H X D)10.71" x 7.48" x 0.80" (272.0 mm x 190.0 mm x 20.4 mm)
GROSS WEIGHT2.1 lb (0.95 Kg) based on configurations
ENVIRONMENTAL
OPERATING TEMPERATURE-4°F ~ 122°F (-20°C ~ 50°C)
STORAGE TEMPERATURE-67°F ~ 158°F (-55°C ~ 70°C)
HUMIDITY0% ~ 90% relative humidity, non-condensing
ENVIRONMENTAL SEALINGIP54
VIBRATION
DROPDrop height: 76 cm
Condition: Based on 2" plywood over concrete
SHOCK
ESDAir charge: +/- 8KV, Contact charge: +/- 4KV
CERTIFICATIONS AND STANDARDSUL60950-1, CE, FCC
POWER SUPPLY
AC/DC ADAPTERAC 100 ~ 240 V, 50 ~ 60 Hz, Output: 12V/ 3A/ 36W
BATTERY LIFELi-ion Battery 8-hour battery life based on test configurations
MASTER BATTERYHot-swappable battery: 14.4V, 2270mAh, 32.7W
SLAVE BATTERY7.4V, 1530mAh, 11.3W
DISPLAY
LCD10.1" TFT-LCD/ 16:10 with LED backlight
RESOLUTION1280 x 800
MAX. COLORSN/A
DOT SIZE0.1692 (H) x 0.1692 (V) mm
BRIGHTNESS300 nits (800 nits optional)
VIEWING ANGLEHorizontal: 170° (Typ.), Vertical: 170° (Typ.)
TOUCH SCREEN
TOUCHSCREEN TYPEProjected capacitive multi-touch screen (PCT)
LIGHT TRANSMISSIONMin 85%
Name Type Version Release Date
RTC-1010M, datasheet Datasheet V2.0 24 November 2020
