FWS-7360

Home  >   AAEON  >   Network Appliance and Video Surveillance  >
Rackmount Network Appliance

1U Rackmount 7 LAN Network Appliance with Intel® Atom™ C3758 SoC Processor

Product Feature

  • Intel® Atom™ C3758 SoC Processor, Optional Support up to 16 Core
  • DDR4 Slot x 4, Support UDIMM/ECC, up to 64GB
  • 5 Copper (2 From 88E1543/ 3 From Intel® I211)
  • 2 10Gb SFP+ (From CPU)
  • Onboard 2 Pairs Bypass
  • Mini-Card Socket (Full-Size) x 1, Mini-Card Socket (Full-Size) with SIM Socket x 1 (Optional)
  • Internal 2.5” SATA HDD x 2
  • LCM with Keypad x 1, RJ-45 Console x 1, USB 3.2 Gen 1 x 2
  • 100W Flex ATX PSU
  • TPM (Optional)

The AAEON FWS-7360 is a 1U enterprise-grade network appliance powered by the Intel Atom C3000 processor series. This high-grade CPU offers Intel QuickAssist Technology (QAT), giving users access to some of the most powerful cryptographic software on the market. Thanks to a unique design feature, the device has two channels with an inbuilt capability to serve as either Mini PCIe slots or 1G LAN ports. The FWS-7360 also boasts DDR4 memory and a range of storage and expansion options, meaning it has both the capacity and the flexibility you need from your next network solution.



SDN/NFV/vCPE Suitable

-Designed with SDN, NFV, and vCPE application in mind
-Its WiFi and 4G LTE capabilities mean it serves employees working without a wired connection.



Onboard Fiber Optic Ports

-The FWS-7360 features built-in 10GbE SFP+ fiber cable ports.
-The ports are connected directly to the CPU, so users have additional expansion slots.



16-Core Processors

-The FWS-7360 can call on up to 16 processing cores, removing the danger of bottlenecks.
-The advanced CPU also reduces the risk of cyber attacks and data loss.



Dual Mini PCIe/LAN Capabilities

-2 ports with both LAN and Mini PCIe functionality
-AAEON can deliver the setup buyers prefer without delays for system redesigns.
-The FWS-7360 is the only rackmount network appliance with this NFV-specific feature.
