The BOXER-6652 is made for the factory floors with its array of electrical protection, which includes over-voltage, low-voltage, surge, reverse polarity and short circuit protection, and inclusion of isolated COMs ports. Its operating temperatures stretches from -20°C to 60°C, a range wider than similar products on the market, and adopts a cable-free design to enhance reliability.
system | |
| CPU | Intel® Core™ i5-4402E, 2.7 GHz |
| Chipset | Intel® QM87 |
| System Memory | DDR3L 1333/1600 SODIMM slot x 1, up to 8 GB |
| Display Interface | VGA, HDMI, DVI-D |
| Storage Device | CFast™, HDD/SSD |
| Ethernet | Intel® I211, 10/100/1000Base-TX x 1 Intel® I217LM, 10/100/1000Base-TX x 1 |
| I/O | Isolated RS-232/422/85 x 2 RS-232 x 4 USB 2.0 x 4 USB 3.2 Gen 1 x 2 VGA x 1 HDMI x 1 DVI x 1 Line-out x 1 LAN x 2 CFast slot x 1 Antenna holes x 2 Power switch Power |
| Expansion | Full-size Mini-Card x 1 (PCI-E + USB, w/ SIM slot) Half-size Mini-Card x 1 (PCI-E + USB) |
| Indicator | Power LED HDD active LED LAN LED |
| OS support | Windows® 7, Windows® 8/8.1, Windows® 10, Linux Fedora |
power supply | |
| Power Requirement | 9 - 30V with 3-pin terminal block |
mechanical | |
| Mounting | Wallmount |
| Dimensions (W x H x D) | 10.4" x 2.74" x 7.62" (264.16mm x 69.62mm x 193.5mm) |
| Gross Weight | 12.1 lb (5.5 kg) |
| Net Weight | 7.7 lb (3.5 kg) |
environmental | |
| Operating Temperature | -4°F ~ 140°F (-20°C ~ 60°C) with wide temperature HDD (according to IEC68-2-14 with 0.5 m/s AirFlow; with industrial devices) |
| Storage Temperature | -4°F ~ 158°F (-20°C ~ 70°C) |
| Storage Humidity | 95% @ 40°C, non-condensing |
| Anti-Vibration | 5 Grms/ 5 ~ 500Hz/ operation –mSATA / SSD 1 Grms/ 5~ 500Hz/ operation – HDD |
| Certification | CE/FCC class A |
