Cellular Interface |
| Cellular Standards | LTE CAT-1, HSPA, UMTS, EDGE, GPRS, GSM |
| LTE Data Rate | 10 MHz bandwidth: 10.2 Mbps DL, 5.2 Mbps UL |
| HSPA Data Rates | 7.2 Mbps DL, 5.76 Mbps UL |
| Band Options (EU) | LTE Band 1 (2100 MHz) / LTE Band 3 (1800 MHz) / LTE Band 8 (900 MHz) /
LTE Band 20 (800 MHz) / LTE Band 28 (700 MHz)
UMTS/HSPA 2100 MHz / 900 MHz
GSM 900 MHz / 1800 MHz |
| Band Options (AU) | LTE Band 3 (1800 MHz) / LTE Band 5 (850 MHz) / LTE Band 8 (900 MHz) /
LTE Band 28 (700 MHz)
UMTS/HSPA 2100 MHz / 850 MHz / 900 MHz |
| No. of SIMs | 2 |
| Cellular Antenna Connectors | 2 SMA female |
Ethernet Interface |
10/100BaseT(X) Ports (RJ45
connector) | 2 |
USB Interface |
| No. of USB Ports | 1 |
| USB Connector | USB Type A |
| USB Standards | USB 2.0 |
Serial Interface |
| No. of Ports | 1 |
| Connector | DB9 male |
| Serial Standards | RS-232/422/485 |
| Data Bits | 5, 6, 7, 8 |
| Stop Bits | 1, 1.5, 2 |
| Parity | None, Even, Odd, Space, Mark |
| Baudrate | 75 bps to 921.6 kbps |
| Console Port | RS-232 (TxD, RxD, GND), 4-pin header output (115200, n, 8, 1) |
Serial Signals |
| RS-232 | TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
| RS-422 | Tx+, Tx-, Rx+, Rx-, GND |
| RS-485-2w | Data+, Data-, GND |
| RS-485-4w | Tx+, Tx-, Rx+, Rx-, GND |
Ethernet Software Features |
| Management | OnCell Central Manager, GuaranLink, DHCP server, DDNS, ARP, Telnet,
TCP/IP, UDP, SMTP, Remote SMS Control, Syslog, SNMPv1/v2c/v3, Serial
Console, Telnet Console, Web Console, Wireless Search Utility |
| Firewall | Filter: MAC, IP protocol, port-based, Access IP list |
| Routing | NAT, Port forwarding |
| Security | HTTPS |
| Time Management | SNTP Client |
IPsec VPN |
| Authentication | PSK/X.509/RSA |
| Encryption | DES, 3DES, AES, MD5, SHA-1, DH2, DH5 |
| Concurrent VPN Tunnels | 5 |
OpenVPN |
| OpenVPN | OpenVPN (client and server), Tunnel mode (routing) and TAP mode (bridge) |
| Encryption | Blowfish CBC, DES CBC, DES-EDE3 CBC, AES-128/192/256 CBC |
| Concurrent VPN Tunnels | 5 |
Power Parameters |
| Input Current | 0.8 A (max.) |
| Input Voltage | 9 to 36 VDC |
| Power Consumption | 5 W (typ.) |
| Power Connector | Terminal block |
| Reverse Polarity Protection | Supported |
| Power Button | Reset button |
Physical Characteristics |
| Housing | Metal |
| IP Rating | IP30 |
| Dimensions | 128.5 x 26 x 89.1 mm (5.06 x 1.02 x 3.51 in) |
| Weight | 550 g (1.22 lb) |
| Installation | DIN-rail mounting, Wall mounting (with optional kit) |
Environmental Limits |
| Operating Temperature | Standard Models: 0 to 55°C (32 to 131°F)
Wide Temp. Models: -30 to 70°C (-22 to 158°F) |
Storage Temperature (package
included) | -40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
Standards and Certifications |
| EMC | EN 55032/24, EN 61000-6-2/-6-4 |
| EMI | CISPR 22, FCC Part 15B Class A |
| EMS | IEC 61000-4-6 CS: 10 V; 150 kHz to 80 MHz
IEC 61000-4-8: 30 A/m
IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV |
| Freefall | IEC 60068-2-32 |
| Hazardous Locations | ATEX, IECEx, Class I Division 2 |
| Radio Frequency | FCC, PTCRB |
| Cellular Standards | EN 301489-1/17
EN 301511
EN 301908-1
AS/CA S042
EN 62311(MPE SAR) |
| Safety | UL 60950-1, UL 62368-1 |
| Shock | IEC 60068-2-27 |
| Vibration | IEC 60068-2-6 |
MTBF |
| Time | 585,775 hrs |
| Standards | Telcordia SR332 |
Warranty |
| Warranty Period | 5 years |
| Details | See www.moxa.com/warranty |
